35HDBNS
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Barrel - Audio Connectors
Description
Conn 3.5MM Stereo Plug PL 3 POS Solder ST Cable Mount 3 Terminal 1 Port
PDF
/
Buying Options
Total Price: USD $8.06
Unit Price: USD $8.0608
≥1 USD $8.0608
≥10 USD $7.14472
≥100 USD $6.869632
≥500 USD $6.594896
≥1000 USD $6.228464
≥3000 USD $5.678878
Inventory: 1367
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Length 43.18mm
Technical
Mating Length/Depth 0.560 14.20mm
Signal Lines Stereo (3 Conductor, TRS)
Actual Diameter 0.138 (3.50mm)
Industry Recognized Mating Diameter 3.50mm (0.141, 1/8, Mini Plug) - Headphone
Body Color Silver, Black
Internal Switch(s) Does Not Contain Switch
Includes 3 pcs - 1 Connector, 1 Handle, 1 Insulator Tube
Number of Positions/Contacts 3 Conductors, 3 Contacts
Cable Opening 0.175 (4.44mm)
Max Voltage Rating (DC) 140.25kV
Number of Poles 3
Number of Ports 1
Max Current Rating 4A
Current Rating 4A
Shielding Unshielded
Orientation Straight
Option GENERAL PURPOSE
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating TIN
Voltage - Rated 250VAC 140VDC
Gender Male
Color Black
Min Operating Temperature 0°C
Max Operating Temperature 66°C
Connector Type Phone Plug
Termination Solder
Number of Terminations 3
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
JESD-609 Code e3
Series 35HD
Published 2002
Packaging Bulk
Physical
Contact Material - Plating Tin
Mounting Type Free Hanging (In-Line)
Mount Cable, Free Hanging
Contact Plating Nickel, Tin
Contact Material Brass
Supply Chain
Factory Lead Time 8 Weeks
