3501FR
RoHS
/
Package /
Category Connectors, Interconnects / Barrel - Audio Connectors
Description
Mono Non-RoHS Compliant 1998 GENERAL PURPOSE Phono (RCA) Jack Connector 0.375 9.52mm
PDF
/
Buying Options
Total Price: USD $2.56
Unit Price: USD $2.556216
≥1 USD $2.556216
≥200 USD $0.989927
≥500 USD $0.954478
≥1000 USD $0.937411
Inventory: 3966
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Technical
Signal Lines Mono
Industry Recognized Mating Diameter 3.20mm ID, 9.00mm OD (RCA)
Panel Hole Size 0.375 9.52mm
Body Color Silver
Internal Switch(s) Does Not Contain Switch
Includes 3 pcs - 1 Connector, 1 Nut, 1 Washer
Number of Positions/Contacts 2 Conductors, 2 Contacts
Thread Size 3/8-32
Number of Poles 2
Number of Ports 1
Configuration 1X1 VERTICAL
Insulation Color Black
Shielding Unshielded
Option GENERAL PURPOSE
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Gender Female
Connector Type Phono (RCA) Jack
Termination Solder Eyelet(s)
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Obsolete
Feature Grounding Tab, Mounting Hardware
Published 1998
Packaging Bulk
Physical
Contact Material - Plating Nickel
Body Material Brass
Mounting Type Panel Mount
