2P1384
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Barrel - Audio Connectors
Description
Conn Miniature Phone Plug PL 2 POS Solder Lug ST Cable Mount 2 Terminal 1 Port
PDF
/
Inventory: 3851
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Length 40.88mm
Technical
Mating Length/Depth 0.563 14.30mm
Signal Lines Mono
Actual Diameter 0.141 (3.57mm)
Industry Recognized Mating Diameter 3.55mm (0.14, Tini Plug)
Body Color Silver
Internal Switch(s) Does Not Contain Switch
Number of Positions/Contacts 2 Conductors, 2 Contacts
Cable Opening 0.219 (5.55mm)
Number of Poles 2
Number of Ports 1
Shielding Unshielded
Orientation Straight
Option GENERAL PURPOSE
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating NOT SPECIFIED
Gender Male
Connector Type Phone Plug
ECCN Code EAR99
Termination Solder
Number of Terminations 2
Part Status Active
JESD-609 Code e3
Series Tini-Plug?
Published 2005
Packaging Bulk
Physical
Contact Material - Plating Nickel
Body Material Copper Alloy
Housing Material Plastic
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Material Copper Alloy
Supply Chain
Factory Lead Time 12 Weeks
