245
RoHS
/
Package /
Category Connectors, Interconnects / Barrel - Audio Connectors
Description
Conn 1/4" Phone Plug M 2 POS Screw ST Cable Mount 2 Terminal 1 Port
PDF
/
Buying Options
Total Price: USD $229.68
Unit Price: USD $229.68
≥1 USD $229.68
Inventory: 32
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status Non-RoHS Compliant
Dimensions
Diameter 6.35mm
Technical
Mating Length/Depth 1.188 30.20mm
Signal Lines Mono
Actual Diameter 0.250 (6.35mm)
Industry Recognized Mating Diameter 6.35mm (0.250, 1/4) - Headphone
Body Color Silver, Red
Internal Switch(s) Does Not Contain Switch
Includes 4 pcs - 1 Connector, 1 Handle, 2 Screws
Number of Positions/Contacts 2 Conductors, 2 Contacts
Wire/Cable Diameter 7.366 mm
Cable Opening 0.297 (7.54mm)
Number of Poles 2
Number of Ports 1
Shielding Unshielded
Orientation Straight
Option GENERAL PURPOSE
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating NOT SPECIFIED
Gender Male
Color Red
Connector Type Phone Plug
ECCN Code EAR99
Termination Screw
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e3
Series LITTEL-PLUG?
Packaging Bulk
Physical
Contact Material - Plating Nickel
Body Material Copper Alloy
Housing Material Plastic
Mounting Type Free Hanging (In-Line)
Mount Cable, Free Hanging
Contact Plating Tin
Contact Material Brass
