238
RoHS
/
Package /
Category Connectors, Interconnects / Barrel - Audio Connectors
Description
CONN PLUG STEREO 6.35MM RA 3COND
PDF
/
Buying Options
Total Price: USD $5.26
Unit Price: USD $5.2624
≥1 USD $5.2624
Inventory: 52
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status Non-RoHS Compliant
REACH SVHC No SVHC
Dimensions
Height 8.59mm
Diameter 6.35mm
Technical
Mating Length/Depth 1.188 30.20mm
Signal Lines Stereo (3 Conductor, TRS)
Actual Diameter 0.250 (6.35mm)
Industry Recognized Mating Diameter 6.35mm (0.250, 1/4) - Headphone
Body Color Silver
Internal Switch(s) Does Not Contain Switch
Includes 5 pcs - 1 Connector, 2 pc Handle, 2 Screws
Number of Positions/Contacts 3 Conductors, 3 Contacts
Number of Poles 3
Cable Length 41.3mm
Number of Ports 1
Housing Color Black
Shielding Shielded
Orientation Right Angle
Option GENERAL PURPOSE
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating NOT SPECIFIED
Voltage - Rated 500VAC
Gender Male
Color Black, Silver
Connector Type Phone Plug
ECCN Code EAR99
Termination Solder
Number of Terminations 3
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Obsolete
JESD-609 Code e3
Series 230
Packaging Bulk
Physical
Contact Material - Plating Tin
Body Material Brass
Housing Material Plastic
Mounting Type Free Hanging (In-Line), Right Angle
Mount Cable, Free Hanging
Contact Plating Nickel, Tin
