152B
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Barrel - Audio Connectors
Description
Stereo (3Conductor TRS) E ROHS3Compliant Straight Phone Jack Connector 65C 250mA 48VDC 0.250 (6.35mm)
PDF
/
Buying Options
Total Price: USD $9.69
Unit Price: USD $9.6888
≥1 USD $9.6888
≥10 USD $8.58968
≥100 USD $8.258976
≥500 USD $7.9288
≥1000 USD $7.755
Inventory: 1067
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Contact Material Copper Alloy
Mount Panel
Mounting Type Panel Mount
Housing Material Thermoplastic
Body Material Brass
Contact Material - Plating Nickel
Technical
Packaging Bulk
Series E
Feature Mounting Hardware, Thread Lock
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Number of Terminations 3
Termination Solder Eyelet(s)
Connector Type Phone Jack
Max Operating Temperature 65°C
Min Operating Temperature -20°C
Gender Female
Voltage - Rated 48VDC
Additional Feature 94V-0
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Orientation Straight
Shielding Unshielded
Current Rating 250mA
Number of Ports 1
Number of Poles 3
Thread Size 15/32-32 NS-2A
Number of Positions/Contacts 3 Conductors, 3 Contacts
Includes 3 pcs - 1 Connector, 1 Nut, 1 Washer
Internal Switch(s) Does Not Contain Switch
Body Color Silver
Panel Hole Size 0.469 11.90mm
Industry Recognized Mating Diameter 6.35mm (0.250, 1/4) - Headphone
Actual Diameter 0.250 (6.35mm)
Signal Lines Stereo (3 Conductor, TRS)
Dimensions
Diameter 6.35mm
Length 15.87mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
