12A
RoHS
RoHS compliant
RoHS compliantPackage Metal
Category Connectors, Interconnects / Barrel - Audio Connectors
Description
CONN JACK MONO 6.35MM PNL MNT
PDF
/
Buying Options
Total Price: USD $3.94
Unit Price: USD $3.9424
≥1 USD $3.9424
≥10 USD $3.57632
≥100 USD $3.150576
≥500 USD $2.431
Inventory: 2491
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Contact Plating Nickel
Mount Chassis, Chassis Mount, Panel, Through Hole
Mounting Type Panel Mount, Through Hole
Package / Case Metal
Weight 10.976935g
Body Material Brass
Contact Material - Plating Tin
Technical
Packaging Bulk
Series LITTEL-JAX?
JESD-609 Code e3
Feature Mounting Hardware, Thread Lock
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Number of Terminations 2
Termination Solder Eyelet(s)
ECCN Code EAR99
Connector Type Phone Jack
Max Operating Temperature 65°C
Min Operating Temperature -20°C
Gender Female
Voltage - Rated 25V
Contact Finish - Mating NOT SPECIFIED
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Option GENERAL PURPOSE
Orientation Straight
Shielding Unshielded
Current Rating 1A
Max Current Rating 1A
Number of Ports 1
Number of Poles 2
Max Voltage Rating (DC) 25V
Thread Size 3/8-32
Number of Positions/Contacts 2 Conductors, 3 Contacts
Includes 3 pcs - 1 Connector, 1 Nut, 1 Washer
Internal Switch(s) Single Switch
Body Color Silver
Panel Hole Size 0.375 9.52mm
Industry Recognized Mating Diameter 6.35mm (0.250, 1/4) - Headphone
Actual Diameter 0.253 (6.43mm)
Signal Lines Mono
Dimensions
Height 10.795mm
Length 32.41mm
Width 76.2mm
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
