114BX
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Barrel - Audio Connectors
Description
Conn Phone Jack F 3 POS Solder Lug ST Panel Mount 3 Terminal 1 Port
PDF
/
Buying Options
Total Price: USD $4.05
Unit Price: USD $4.048
≥1 USD $4.048
≥10 USD $3.67312
≥100 USD $2.750704
≥500 USD $2.497
Inventory: 2717
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC Unknown
Dimensions
Length 15.87mm
Height 15.87mm
Technical
Signal Lines Stereo (3 Conductor, TRS)
Actual Diameter 0.250 (6.35mm)
Industry Recognized Mating Diameter 6.35mm (0.250, 1/4) - Headphone
Panel Hole Size 0.375 9.52mm
Body Color Silver, Black
Internal Switch(s) Two Switches
Includes 3 pcs - 1 Connector, 1 Nut, 1 Washer
Number of Positions/Contacts 3 Conductors, 5 Contacts
Thread Size 3/8-32
Number of Poles 3
Number of Ports 1
Current Rating 3A
Depth 34.77mm
Shielding Unshielded
Orientation Straight
Option GENERAL PURPOSE
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating TIN
Voltage - Rated 48VDC
Gender Female
Color Black
Connector Type Phone Jack
ECCN Code EAR99
Termination Solder Eyelet(s)
Number of Terminations 3
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Feature Mounting Hardware, Thread Lock
Series Hi-D? 11*
Published 2008
Packaging Bulk
Operating Temperature -20°C~65°C
Physical
Contact Material - Plating Tin
Body Material Brass
Housing Material Polyester, Glass Filled
Mounting Type Panel Mount, Through Hole
Mount Chassis Mount, Panel, Through Hole
Contact Plating Nickel, Tin
Supply Chain
Factory Lead Time 12 Weeks
