113BX
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Barrel - Audio Connectors
Description
Conn Phone Jack F 3 POS Solder Lug ST Panel Mount 3 Terminal 1 Port
PDF
/
Buying Options
Total Price: USD $3.42
Unit Price: USD $3.4232
≥1 USD $3.4232
≥10 USD $3.1064
≥100 USD $2.942016
≥500 USD $2.873376
≥1000 USD $2.736624
≥3000 USD $2.409018
Inventory: 1467
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Contact Plating Nickel, Tin
Mount Chassis Mount, Panel, Through Hole
Mounting Type Panel Mount, Through Hole
Housing Material Polyester, Glass Filled
Body Material Brass
Contact Material - Plating Tin
Technical
Operating Temperature -20°C~65°C
Packaging Bulk
Published 2008
Series Hi-D? 11*
Feature Mounting Hardware, Thread Lock
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Number of Terminations 3
Termination Solder Eyelet(s)
ECCN Code EAR99
Connector Type Phone Jack
Color Black
Gender Female
Voltage - Rated 48VDC
Contact Finish - Mating TIN
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Option GENERAL PURPOSE
Orientation Straight
Shielding Unshielded
Current Rating 3A
Number of Ports 1
Number of Poles 3
Thread Size 3/8-32
Number of Positions/Contacts 3 Conductors, 4 Contacts
Includes 3 pcs - 1 Connector, 1 Nut, 1 Washer
Internal Switch(s) Single Switch
Body Color Silver, Black
Panel Hole Size 0.375 9.52mm
Industry Recognized Mating Diameter 6.35mm (0.250, 1/4) - Headphone
Actual Diameter 0.250 (6.35mm)
Signal Lines Stereo (3 Conductor, TRS)
Dimensions
Length 15.87mm
Compliance
RoHS Status ROHS3 Compliant
