112APCX image
Favorite
112APCX image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Barrel - Audio Connectors
Description SWITCHCRAFT 112APCX Phone Audio Connector, Socket, 6.35 mm, 2 Contacts, PCB Mount
PDF
/
Buying Options
Total Price: USD $2.78
Unit Price: USD $2.7808
≥1 USD $2.7808
≥10 USD $2.52472
≥100 USD $2.391136
≥500 USD $2.33552
≥1000 USD $2.224288
≥3000 USD $1.958
Inventory: 6024
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC

Dimensions

Width 15.7mm
Length 15.87mm

Technical

Signal Lines Mono
Actual Diameter 0.250 (6.35mm)
Industry Recognized Mating Diameter 6.35mm (0.250, 1/4) - Headphone
Panel Hole Size 0.375 9.52mm
Body Color Silver, Black
Internal Switch(s) Single Switch
Includes 3 pcs - 1 Connector, 1 Nut, 1 Washer
Number of Positions/Contacts 2 Conductors, 3 Contacts
Thread Size 3/8-32
Number of Poles 5
Number of Ports 1
Number of Contacts 2
Current Rating 3A
Depth 27.64mm
Shielding Unshielded
Orientation Straight
Option GENERAL PURPOSE
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating TIN
Voltage - Rated 48VDC
Gender Female
Color Black
Connector Type Phone Jack
ECCN Code EAR99
Termination Solder
Number of Terminations 5
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Feature Mounting Hardware, Thread Lock
Series Hi-D? 11*
Published 1998
Packaging Bulk
Operating Temperature -20°C~65°C

Physical

Contact Material - Plating Tin
Body Material Brass
Housing Material Polyester, Glass Filled
Mounting Type Panel Mount, Through Hole
Mount Panel, Through Hole
Contact Plating Nickel, Tin

Supply Chain

Factory Lead Time 12 Weeks
