RoHS
RoHS compliant
RoHS compliantPackage 125
Category Connectors, Interconnects / Barrel - Audio Connectors
Description
CONN RCA JACK MONO 3.2MM R/A
PDF
/
Buying Options
Total Price: USD $1.45
Unit Price: USD $1.454149
≥1 USD $1.454149
≥10 USD $1.371838
≥100 USD $1.294182
≥500 USD $1.220932
≥1000 USD $1.151824
Inventory: 8391
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Width 14mm
Length 10mm
Height 13mm
Technical
Signal Lines Mono
Actual Diameter 0.125 (3.18mm ID), 0.327 (8.31mm OD)
Industry Recognized Mating Diameter 3.20mm ID, 9.00mm OD (RCA)
Body Color Silver, White
Internal Switch(s) Single Switch
Number of Positions/Contacts 2 Conductors, 3 Contacts
Number of Ports 1
Number of Contacts 3
Insulation Color White
Shielding Unshielded
Orientation Horizontal
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating NOT SPECIFIED
Gender Female
Number of Positions 2
Connector Type Phono (RCA) Jack
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Board Lock
Packaging Bulk
Physical
Contact Material - Plating Nickel
Body Material Brass
Housing Material Polybutylene Terephthalate (PBT)
Package / Case 125
Mounting Type Through Hole, Right Angle
Mount PC Mount, Panel, Through Hole
Contact Plating Silver
Contact Material Brass, Phosphor Bronze
Supply Chain
Factory Lead Time 6 Weeks
