RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Barrel - Audio Connectors
Description RCA Phono Connectors R/A PC PHONO JACK
PDF
/
Inventory: /
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 6 Weeks

Physical

Contact Material Brass
Mount PC Mount, PCB, Through Hole
Mounting Type Through Hole, Right Angle
Insulation Material Nickel
Body Material Steel
Contact Material - Plating Tin

Technical

Packaging Bulk
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Connector Type Phono (RCA) Jack
Color Black, Natural
Gender Female
Contact Finish - Mating NOT SPECIFIED
Option GENERAL PURPOSE
Orientation Right Angle
Shielding Unshielded
Insulation Color Black
Number of Ports 1
Number of Poles 1
Number of Positions/Contacts 2 Conductors, 2 Contacts
Internal Switch(s) Does Not Contain Switch
Body Color Silver
Industry Recognized Mating Diameter 3.20mm ID, 9.00mm OD (RCA)
Signal Lines Mono

Dimensions

Length 14.5mm

Compliance

RoHS Status ROHS3 Compliant
Lead Free Lead Free
