SJ1-3534
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Barrel - Audio Connectors
Description
Stereo (3Conductor TRS) SJ1 RoHS Compliant 2014 Phone Jack Connector -25C~85C 1A 12VDC 0.142 (3.60mm)
PDF
/
Buying Options
Total Price: USD $1.54
Unit Price: USD $1.54
≥1 USD $1.54
≥10 USD $1.34288
≥100 USD $1.285504
≥500 USD $1.25708
≥1000 USD $1.19988
≥3000 USD $1.08563
Inventory: 4292
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Physical
Contact Material Brass
Contact Plating Tin
Mount Panel, Through Hole
Mounting Type Panel Mount, Through Hole, Right Angle
Housing Material Polybutylene Terephthalate (PBT)
Body Material Brass
Contact Material - Plating Tin
Technical
Operating Temperature -25°C~85°C
Packaging Tray
Published 2014
Series SJ1
Feature Mounting Hardware, Thread Lock
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Connector Type Phone Jack
Color Black
Gender Female
Voltage - Rated 12VDC
Current Rating (Amps) 1A
Orientation Horizontal
Shielding Unshielded
Current Rating 1A
Number of Conductors 3
Number of Ports 1
Thread Size M6
Number of Positions/Contacts 3 Conductors, 4 Contacts
Includes 2 pcs - 1 Connector, 1 Nut
Internal Switch(s) Single Switch
Body Color Silver, Black
Panel Hole Size 0.236 5.99mm
Industry Recognized Mating Diameter 3.50mm (0.141, 1/8, Mini Plug) - Headphone
Actual Diameter 0.142 (3.60mm)
Signal Lines Stereo (3 Conductor, TRS)
Mating Length/Depth 0.551 14.00mm
Dimensions
Diameter 3.5mm
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
