SJ-3552B-MSMT-TR-67
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Barrel - Audio Connectors
Description
5Conductor (TRRRS) SJ RoHS Compliant Single Switch Phone Jack Connector -30C~85C 1A 12VDC 0.142 (3.60mm)
PDF
/
Buying Options
Total Price: USD $3.98
Unit Price: USD $3.9776
≥1 USD $3.9776
≥10 USD $3.6124
≥100 USD $3.421792
≥500 USD $3.34224
≥1000 USD $3.183136
≥3000 USD $2.7852
Inventory: 2763
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 13 Weeks
Physical
Contact Material Copper Alloy, Titanium (Ti)
Mounting Type Board Cutout, Surface Mount, Right Angle
Housing Material Polyamide (PA9T), Nylon 9T
Contact Material - Plating Gold
Technical
Operating Temperature -30°C~85°C
Packaging Tape & Reel (TR)
Series SJ
Feature IP67
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Connector Type Phone Jack
Gender Female
Voltage - Rated 12VDC
Current Rating (Amps) 1A
Shielding Unshielded
Number of Positions/Contacts 5 Conductors, 6 Contacts
Includes 2 pcs - 1 Connector, 1 O-Ring
Internal Switch(s) Single Switch
Body Color Black
Industry Recognized Mating Diameter 3.50mm (0.141, 1/8, Mini Plug) - Headphone
Actual Diameter 0.142 (3.60mm)
Signal Lines 5 Conductor (TRRRS)
Mating Length/Depth 0.551 14.00mm
Compliance
RoHS Status RoHS Compliant
