SJ-3525NG
RoHS
/
Package /
Category Connectors, Interconnects / Barrel - Audio Connectors
Description
CONN JACK STEREO 3.5MM R/A
PDF
/
Inventory: 6637
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Brass; Copper Alloy
Contact Plating Nickel
Mount Through Hole
Mounting Type Through Hole, Right Angle
Housing Material Polybutylene Terephthalate (PBT)
Body Material Brass
Contact Material - Plating Silver
Technical
Operating Temperature -25°C~85°C
Packaging Bulk
Published 2004
Series SJ
Part Status Obsolete
Moisture Sensitivity Level (MSL) Not Applicable
Termination Solder
Connector Type Phone Jack
Color Black
Gender Female
Voltage - Rated 12VDC
Shielding Unshielded
Current Rating 1A
Number of Positions/Contacts 3 Conductors, 5 Contacts
Internal Switch(s) Single Switch
Body Color Silver, Black
Industry Recognized Mating Diameter 3.50mm (0.141, 1/8, Mini Plug) - Headphone
Actual Diameter 0.142 (3.60mm)
Signal Lines Stereo (3 Conductor, TRS)
Mating Length/Depth 0.551 14.00mm
Dimensions
Diameter 3.5mm
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
