SJ-3505
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Barrel - Audio Connectors
Description
CONN JACK STEREO 3.5MM R/A
PDF
/
Inventory: 7038
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 9 Weeks
Physical
Contact Material Brass, Copper Alloy, Tin Bronze
Contact Plating Silver
Mount Through Hole
Mounting Type Through Hole, Right Angle
Housing Material Polybutylene Terephthalate (PBT)
Contact Material - Plating Silver
Technical
Operating Temperature -25°C~85°C
Packaging Bulk
Published 2011
Series SJ
Part Status Last Time Buy
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Connector Type Phone Jack
Number of Positions 2
Color Black
Gender Female
Voltage - Rated 12VDC
Current Rating (Amps) 1A
Orientation Horizontal
Shielding Unshielded
Current Rating 1A
Number of Conductors 3
Number of Ports 1
Number of Positions/Contacts 3 Conductors, 5 Contacts
Internal Switch(s) Two Switches
Body Color Black
Industry Recognized Mating Diameter 3.50mm (0.141, 1/8, Mini Plug) - Headphone
Actual Diameter 0.142 (3.60mm)
Signal Lines Stereo (3 Conductor, TRS)
Dimensions
Diameter 3.5mm
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
