RCP-011
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Barrel - Audio Connectors
Description
CONN RCA PLUG MONO 2COND
PDF
/
Inventory: 9609
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Contact Material Brass
Contact Plating Nickel
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Housing Material Acrylonitrile Butadiene Styrene (ABS)
Body Material Brass
Contact Material - Plating Nickel
Technical
Operating Temperature -20°C~85°C
Packaging Bulk
Published 2011
Series RCP
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder Eyelet(s)
Connector Type Phono (RCA) Plug
Max Operating Temperature 85°C
Min Operating Temperature -20°C
Color Black
Gender Male
Voltage - Rated 12VDC
Current Rating (Amps) 5A
Orientation Vertical
Shielding Unshielded
Housing Color Black
Number of Positions/Contacts 2 Conductors, 2 Contacts
Includes 2 pcs - 1 Connector, 1 Handle
Internal Switch(s) Does Not Contain Switch
Body Color Silver, Black
Industry Recognized Mating Diameter 3.20mm ID, 9.00mm OD (RCA)
Actual Diameter 0.126 (3.20mm ID), 0.354 (9.00mm OD)
Signal Lines Mono
Mating Length/Depth 0.563 14.30mm
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
