RCJ-026

CUI Devices
RoHS
RoHS RoHS compliant
Package Metal
Category Connectors, Interconnects / Barrel - Audio Connectors
Description CONN RCA JACK MONO 3.2MM PCB
PDF
/
Buying Options
Total Price: USD $1.02
Unit Price: USD $1.0208
≥1 USD $1.0208
≥10 USD $0.85976
≥100 USD $0.825088
≥500 USD $0.807488
≥1000 USD $0.772376
≥3000 USD $0.70217
Inventory: 1112
Minimum: 1
-
+

Technical Details

Technical

Shielding Unshielded
Insulation Color Green
Number of Ports 1
Number of Positions/Contacts 2 Conductors, 2 Contacts
Internal Switch(s) Does Not Contain Switch
Body Color Silver
Industry Recognized Mating Diameter 3.20mm ID, 9.00mm OD (RCA)
Actual Diameter 0.138 (3.50mm ID), 0.327 (8.30mm OD)
Signal Lines Mono
Orientation Vertical
Gender Female
Color Green
Connector Type Phono (RCA) Jack
Termination Solder
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Feature Board Lock
Series RCJ
Published 2011
Packaging Bulk
Operating Temperature -20°C~85°C

Dimensions

Diameter 3.5mm

Compliance

RoHS Status RoHS Compliant
Lead Free Lead Free

Physical

Contact Material - Plating Nickel
Body Material Brass
Package / Case Metal
Mounting Type Through Hole
Mount Through Hole
Contact Plating Nickel
Contact Material Brass

Supply Chain

Factory Lead Time 11 Weeks
