MJ-2507
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Barrel - Audio Connectors
Description
audio jack, 2.5 mm, vertical, mono, through hole, 1 switch
PDF
/
Buying Options
Total Price: USD $0.55
Unit Price: USD $0.548792
≥1 USD $0.548792
≥200 USD $0.21269
≥500 USD $0.204812
≥1000 USD $0.200874
Inventory: 9375
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Physical
Contact Material Brass; Copper Alloy
Mounting Type Panel Mount, Through Hole, Right Angle
Housing Material Polybutylene Terephthalate (PBT)
Body Material Brass
Technical
Operating Temperature -25°C~85°C
Packaging Bulk
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Connector Type Phone Jack
Color Black
Gender Female
Voltage - Rated 12VDC
Current Rating (Amps) 1A
Orientation Vertical
Shielding Unshielded
Number of Conductors 2
Number of Ports 1
Thread Size M4X0.5
Number of Positions/Contacts 2 Conductors, 3 Contacts
Internal Switch(s) Single Switch
Body Color Silver, Black
Industry Recognized Mating Diameter 2.50mm (0.094, 3/32, Sub Mini, Miniature) - Headphone
Actual Diameter 0.102 (2.60mm)
Signal Lines Mono
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
