MJ-2506

CUI Devices
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Barrel - Audio Connectors
Description CONN JACK MONO 2.5MM R/A
PDF
/
Buying Options
Total Price: USD $0.58
Unit Price: USD $0.57505
≥1 USD $0.57505
≥200 USD $0.223193
≥500 USD $0.215316
≥1000 USD $0.211377
Inventory: 2592
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 11 Weeks

Physical

Contact Material Brass; Copper Alloy
Contact Plating Tin
Mount Panel, Through Hole
Mounting Type Panel Mount, Through Hole, Right Angle
Housing Material Polybutylene Terephthalate (PBT)
Body Material Brass
Contact Material - Plating Tin

Technical

Packaging Bulk
Published 2011
Feature Mounting Hardware, Thread Lock
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Solder
Connector Type Phone Jack
Color Black
Gender Female
Voltage - Rated 12VDC
Current Rating (Amps) 1A
Orientation Horizontal
Shielding Unshielded
Current Rating 1A
Number of Conductors 2
Number of Ports 1
Number of Positions/Contacts 2 Conductors, 3 Contacts
Includes 2 pcs - 1 Connector, 1 Nut
Internal Switch(s) Single Switch
Body Color Silver, Black
Industry Recognized Mating Diameter 2.50mm (0.094, 3/32, Sub Mini, Miniature) - Headphone
Actual Diameter 0.102 (2.60mm)
Signal Lines Mono

Dimensions

Diameter 2.5mm

Compliance

RoHS Status RoHS Compliant
Lead Free Lead Free
