ACPS-KB
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Barrel - Audio Connectors
Description
Barrel Audio Connector
PDF
/
Buying Options
Total Price: USD $4.21
Unit Price: USD $4.209157
≥1 USD $4.209157
≥200 USD $1.629309
≥500 USD $1.571541
≥1000 USD $1.54397
Inventory: 6563
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Contact Material Brass
Contact Plating Nickel
Mount Cable
Mounting Type Free Hanging (In-Line)
Housing Material Zinc Alloy
Contact Material - Plating Nickel
Technical
Operating Temperature -25°C~70°C
Published 2011
Series M
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder Eyelet(s)
Connector Type Phone Plug
Max Operating Temperature 75°C
Min Operating Temperature -25°C
Gender Male
Current Rating (Amps) 10A
Orientation Straight
Shielding Unshielded
Number of Ports 1
Number of Positions/Contacts 3 Conductors, 3 Contacts
Internal Switch(s) Does Not Contain Switch
Body Color Silver, Black
Industry Recognized Mating Diameter 6.35mm (0.250, 1/4) - Headphone
Actual Diameter 0.249 (6.32mm)
Signal Lines Stereo (3 Conductor, TRS)
Mating Length/Depth 1.190 30.30mm
Dimensions
Diameter 13.8mm
Length 79mm
Compliance
RoHS Status ROHS3 Compliant
Flammability Rating UL94 V-0
