ASJ-190-C
RoHS
/
Package /
Category Connectors, Interconnects / Barrel - Audio Connectors
Description
Barrel Audio Connector
PDF
/
Inventory: 2251
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Phosphor Bronze
Mounting Type Through Hole, Right Angle
Housing Material Polybutylene Terephthalate (PBT)
Contact Material - Plating Silver
Technical
Operating Temperature -20°C~70°C
Packaging Bulk
Series ASJ
Feature Board Guide
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Connector Type Phone Jack
Gender Female
Voltage - Rated 30VDC
Current Rating (Amps) 500mA
Shielding Unshielded
Insulation Color Black
Number of Positions/Contacts 3 Conductors, 4 Contacts
Internal Switch(s) Single Switch
Industry Recognized Mating Diameter 2.50mm ID (0.098)
Actual Diameter 0.102 (2.60mm)
Signal Lines Stereo (3 Conductor, TRS)
Mating Length/Depth 0.433 11.00mm
