3770-6
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Banana and Tip Connectors - Binding Posts
Description
PANEL MOUNT POLYCARBONATE Tip Binding Post Connector
PDF
/
Inventory: 2417
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Material - Insulation Polycarbonate (PC)
Material - Body Copper
Nut Material Brass
Technical
Published 2005
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) Not Applicable
Termination Threaded and Turret
Type Standard
Color Blue
Voltage - Rated 33Vrms/70VDC
Additional Feature PANEL MOUNT, POLYCARBONATE
Voltage - Rated DC 70V
Current Rating 15A
Hole Diameter 2.4384 mm
Plating - Body Gold
Head Style Knurled
Head Size 0.440 OD 11.18mm
Cross Hole Diameter 0.096 (2.43mm)
Termination Thread 8-32
Nut Plating Nickel
Dimensions
Panel Thickness 0.070 ~ 0.250 1.77mm ~ 6.35mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
