3770-0 image
Favorite
3770-0 image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Banana and Tip Connectors - Binding Posts
Description ROHS3Compliant 2003 Gold Straight Binding Post Connector 15A 2.5kV 11.18mm
PDF
/
Buying Options
Total Price: USD $26.63
Unit Price: USD $26.630864
≥1 USD $26.630864
≥200 USD $10.626613
≥500 USD $10.270817
≥1000 USD $10.096201
Inventory: 7344
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC

Dimensions

Panel Thickness 0.070 ~ 0.250 1.77mm ~ 6.35mm
Length 45.21mm

Technical

Nut Plating Nickel
Termination Thread 8-32
Cross Hole Diameter 0.096 (2.43mm)
Head Size 0.440 OD 11.18mm
Head Style Knurled
Plating - Body Gold
Hole Diameter 2.4384 mm
Max Current Rating 15A
Number of Contacts 1
Voltage - Rated AC 2.5kV
Current Rating 15A
Depth 11.18mm
Orientation Straight
Voltage - Rated DC 2.5kV
HTS Code 8536.90.40.00
Color Black
Type Standard
ECCN Code EAR99
Termination Threaded and Turret
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Pbfree Code yes
Published 2003

Physical

Nut Material Brass
Material - Body Copper
Material - Insulation Polycarbonate (PC)
Housing Material Polycarbonate
Mount Panel

Supply Chain

Factory Lead Time 2 Weeks
