3760-2
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Banana and Tip Connectors - Binding Posts
Description
ROHS3Compliant 2001 Tin Lead Free Binding Post Connector 15A 33Vrms/70VDC 0.096 (2.43mm)
PDF
/
Buying Options
Total Price: USD $4.83
Unit Price: USD $4.8312
≥1 USD $4.8312
≥10 USD $4.708
Inventory: 1173
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 2 Weeks
Physical
Material - Insulation Polycarbonate (PC)
Material - Body Brass
Technical
Packaging Bulk
Published 2001
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Threaded and Turret
ECCN Code EAR99
Type Standard
Color Red
Voltage - Rated 33Vrms/70VDC
Additional Feature PANEL MOUNT, POLYCARBONATE
Voltage - Rated DC 2.5kV
Current Rating 15A
Plating - Body Tin
Head Style Knurled
Head Size 0.440 OD 11.18mm
Cross Hole Diameter 0.096 (2.43mm)
Termination Thread 8-32
Nut Plating Nickel
Dimensions
Panel Thickness 0.070 ~ 0.250 1.77mm ~ 6.35mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
