7006
RoHS
RoHS compliant
RoHS compliantPackage 508
Category Connectors, Interconnects / Banana and Tip Connectors - Binding Posts
Description
POST BINDING ECON NYLON-INS RED
PDF
/
Buying Options
Total Price: USD $6.29
Unit Price: USD $6.292
≥1 USD $6.292
≥10 USD $5.505984
≥100 USD $4.98168
≥500 USD $4.746509
≥1000 USD $4.444018
≥3000 USD $3.775209
Inventory: 1882
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Panel Thickness 0.313 7.95mm
Length 34.6mm
Technical
Termination Thread 6-32
Cross Hole Diameter 0.086 (2.18mm)
Head Size 0.423 ODx0.719L 10.74mmx18.26mm
Head Style Knurled
Plating - Body Nickel
Hole Diameter 2.1844 mm
Insulation Non-Insulated
Voltage - Rated AC 1kV
Current Rating 15A
HTS Code 8536.69.40.30
Voltage - Rated 1000VAC
Color Red
Type Standard
ECCN Code EAR99
Termination Threaded
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Packaging Bulk
Physical
Nut Material Steel
Material - Body Brass
Material - Insulation Polyamide (PA), Nylon
Package / Case 508
Supply Chain
Factory Lead Time 6 Weeks
