CX2078NL
RoHS
RoHS compliant
RoHS compliantPackage 6-SMD, Gull Wing
Category RF/IF and RFID / Balun
Description
BALUN 5MHZ-500MHZ 50/50 6SMD GW
PDF
/
Buying Options
Total Price: USD $8.33
Unit Price: USD $8.325099
≥1 USD $8.325099
≥200 USD $3.321637
≥500 USD $3.211353
≥1000 USD $3.156212
Inventory: 1973
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Length 4.3mm
Technical
Impedance - Unbalanced/Balanced 50 / 50Ohm
Insertion Loss (Max) 2.5dB
Turns Ratio - Primary:Secondary 1:1
Transformer Type RF TRANSFORMER
Insertion Loss (dB) 0.6 dB
Frequency Range 5MHz~500MHz
Lead/Base Style Gull Wing
Frequency 500MHz
Depth 5.3mm
Min Operating Temperature -40°C
Max Operating Temperature 85°C
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Published 2009
Packaging Tray
Physical
Number of Pins 6
Package / Case 6-SMD, Gull Wing
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 9 Weeks
