CX2074NL
RoHS
RoHS compliant
RoHS compliantPackage 6-SMD Module
Category RF/IF and RFID / Balun
Description
BALUN 1MHZ-500MHZ 1:4 6SMD MODUL
PDF
/
Buying Options
Total Price: USD $2.42
Unit Price: USD $2.42
≥1 USD $2.42
≥10 USD $1.96152
≥100 USD $1.58576
≥500 USD $1.48566
≥1000 USD $1.469494
Inventory: 1464
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Width 4mm
Length 6.9mm
Height 4.4mm
Technical
Impedance - Unbalanced/Balanced 1:4
Turns Ratio - Primary:Secondary 1:2
Transformer Type RF TRANSFORMER
Insertion Loss (dB) 0.6 dB
Frequency Range 1MHz~500MHz
Lead/Base Style Gull Wing
Depth 4mm
Min Operating Temperature -40°C
Max Operating Temperature 85°C
ECCN Code EAR99
Termination SMD/SMT
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Published 2004
Packaging Tray
Physical
Number of Pins 6
Package / Case 6-SMD Module
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 11 Weeks
