CX2074 image
Favorite
CX2074 image
Favorite
RoHS
/
Package 6-SMD
Category RF/IF and RFID / Balun
Description Audio Transformers / Signal Transformers SMD RF Xfmr 75Ohms
PDF
/
Inventory: 4864
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status Non-RoHS Compliant

Dimensions

Width 4mm
Length 6.9mm
Height 4.4mm

Technical

Impedance - Unbalanced/Balanced 1:4
Cut-off Frequency-Min 1MHz
Cut-off Frequency-Max 500MHz
Turns Ratio (NpNs) 1:2CT
Insertion Loss (Max) 0.6dB
Transformer Type RF TRANSFORMER
Frequency Range 1MHz~500MHz
Operating Temperature (Min) -40°C
Physical Dimension 6.9mm X 4.0mm X 4.4mm
Operating Temperature (Max) 85°C
Packing Method TRAY
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Published 2012

Physical

Surface Mount YES
Package / Case 6-SMD
Mounting Type Surface Mount
