CX2049LNLT
RoHS
RoHS compliant
RoHS compliantPackage 5-SMD Module
Category RF/IF and RFID / Balun
Description
RF Transformer 1:2.83 0.5MHz to 1500MHz Surface Mount
PDF
/
Buying Options
Total Price: USD $3.41
Unit Price: USD $3.4144
≥1 USD $3.4144
≥10 USD $2.76408
≥100 USD $2.234848
≥500 USD $2.093696
≥1000 USD $1.999624
≥3000 USD $1.940787
Inventory: 2387
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Width 3.81mm
Length 3.81mm
Height 2.79mm
Technical
Insertion Loss (Max) 1.2dB
Turns Ratio - Primary:Secondary 1:2.83
Transformer Type RF TRANSFORMER
Frequency Range 250KHz~500MHz
Physical Dimension L3.81XB3.81XH2.79 (mm)
Frequency 1.5GHz
Additional Feature IMPEDANCE RATIO IS 1:8CT; HEIGHT DIM INCLUDES TERMINALS ALSO
Min Operating Temperature -40°C
Max Operating Temperature 85°C
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Published 2010
Packaging Tape & Reel (TR)
Physical
Package / Case 5-SMD Module
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 9 Weeks
