CX2047LANLT
RoHS
RoHS compliant
RoHS compliantPackage 6-SMD Module, 5 Leads
Category RF/IF and RFID / Balun
Description
BALUN 500KHZ-300MHZ 1:4 6SMD MOD
PDF
/
Buying Options
Total Price: USD $2.6
Unit Price: USD $2.6048
≥1 USD $2.6048
≥10 USD $2.112
≥100 USD $1.707904
≥500 USD $1.600016
≥1000 USD $1.528032
≥3000 USD $1.483082
Inventory: 1250
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 9 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 6-SMD Module, 5 Leads
Number of Pins 5
Technical
Packaging Tape & Reel (TR)
Published 2014
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Subcategory Other Transformers
Physical Dimension 3.81mm x 3.81mm x 3.07mm
Operating Temperature (Min) -40°C
Application MATCHING
Frequency Range 500KHz~300MHz
Operating Frequency-Max 300000kHz
Transformer Type RF TRANSFORMER
Insertion Loss (Max) 4.0dB
Number of Secondary Winding 1
Number of Primary Winding 1
Return Loss-Min 14dB
Impedance - Unbalanced/Balanced 1:4
Dimensions
Height 3.07mm
Length 3.81mm
Width 3.81mm
Compliance
RoHS Status RoHS Compliant
