CX2044LNL
RoHS
RoHS compliant
RoHS compliantPackage 5-SMD
Category RF/IF and RFID / Balun
Description
RF Transformer 1.5:1 5MHz to 500MHz Surface Mount
PDF
/
Buying Options
Total Price: USD $3.38
Unit Price: USD $3.3792
≥1 USD $3.3792
≥10 USD $2.73768
≥100 USD $2.213728
≥500 USD $2.07394
≥1000 USD $1.980704
≥3000 USD $1.922448
Inventory: 1288
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 9 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 5-SMD
Technical
Packaging Tray
Published 2010
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Additional Feature IMPEDANCE RATIO IS 1.5:1; HEIGHT DIM INCLUDES TERMINALS ALSO
Reach Compliance Code unknown
Frequency 1.5GHz
Physical Dimension L3.81XB3.81XH2.79 (mm)
Frequency Range 5MHz~500MHz
Transformer Type RF TRANSFORMER
Turns Ratio - Primary:Secondary 1.22:1
Insertion Loss (Max) 0.5dB
Return Loss-Min -15dB
Impedance - Unbalanced/Balanced 50 / 50Ohm
Dimensions
Height 2.79mm
Length 3.81mm
Width 3.81mm
Compliance
RoHS Status RoHS Compliant
