CX2043LNLT
RoHS
RoHS compliant
RoHS compliantPackage 5-SMD Module
Category RF/IF and RFID / Balun
Description
RF Transformer 1.22:1 5Term. SMD
PDF
/
Buying Options
Total Price: USD $3.8
Unit Price: USD $3.8016
≥1 USD $3.8016
≥10 USD $3.07736
≥100 USD $2.487936
≥500 USD $2.330768
≥1000 USD $2.22596
≥3000 USD $2.16047
Inventory: 770
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Length 3.81mm
Height 2.79mm
Technical
Impedance - Unbalanced/Balanced 1.5:1
Turns Ratio - Primary:Secondary 1.22:1
Transformer Type RF TRANSFORMER
Insertion Loss (dB) 0.2 dB
Frequency Range 1MHz~1GHz
Physical Dimension L3.81XB3.81XH2.79 (mm)
Frequency 1.5GHz
Depth 3.81mm
Min Operating Temperature -40°C
Max Operating Temperature 85°C
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Published 2010
Packaging Tape & Reel (TR)
Physical
Number of Pins 5
Package / Case 5-SMD Module
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 14 Weeks
