CX2041NLT
RoHS
RoHS compliant
RoHS compliantPackage 5-SMD Module
Category RF/IF and RFID / Balun
Description
RF Transformer 1:1CT 5Term. SMD
PDF
/
Buying Options
Total Price: USD $2.9
Unit Price: USD $2.8952
≥1 USD $2.8952
≥10 USD $2.34696
≥100 USD $1.897632
≥500 USD $1.777776
≥1000 USD $1.697872
≥3000 USD $1.647923
Inventory: 833
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Length 3.81mm
Height 2.79mm
Technical
Impedance - Unbalanced/Balanced 75 / 75Ohm
Return Loss-Min -25dB
Number of Primary Winding 1
Number of Secondary Winding 1
Insertion Loss (Max) 0.8dB
Turns Ratio - Primary:Secondary 1:1
Transformer Type RF TRANSFORMER
Insertion Loss (dB) 0.6 dB
Frequency Range 50kHz~450MHz
Application SIGNAL
Physical Dimension L3.81XB3.81XH2.79 (mm)
Approval Agency UL
Frequency 1.5GHz
Depth 3.81mm
Subcategory Other Transformers
Min Operating Temperature -40°C
Max Operating Temperature 85°C
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Published 2010
Packaging Tape & Reel (TR)
Physical
Number of Pins 5
Package / Case 5-SMD Module
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 9 Weeks
