CX2041NL
RoHS
RoHS compliant
RoHS compliantPackage 5-SMD Module
Category RF/IF and RFID / Balun
Description
RF Transformer 1:1CT 5Term. SMD
PDF
/
Buying Options
Total Price: USD $1.21
Unit Price: USD $1.212597
≥1 USD $1.212597
≥10 USD $0.483372
≥100 USD $0.468093
≥500 USD $0.459759
Inventory: 1226
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 9 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 5-SMD Module
Number of Pins 5
Technical
Packaging Tray
Published 2010
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Subcategory Other Transformers
Depth 3.81mm
Frequency 1.5GHz
Approval Agency UL
Physical Dimension L3.81XB3.81XH2.79 (mm)
Application SIGNAL
Frequency Range 50kHz~450MHz
Insertion Loss (dB) 0.6 dB
Transformer Type RF TRANSFORMER
Turns Ratio - Primary:Secondary 1:1
Insertion Loss (Max) 0.8dB
Number of Secondary Winding 1
Number of Primary Winding 1
Return Loss-Min -25dB
Impedance - Unbalanced/Balanced 75 / 75Ohm
Dimensions
Height 2.79mm
Length 3.81mm
Compliance
RoHS Status RoHS Compliant
