CX2040LNLT
RoHS
RoHS compliant
RoHS compliantPackage 5-SMD Module
Category RF/IF and RFID / Balun
Description
RF Transformer 1:1 5Term. SMD
PDF
/
Buying Options
Total Price: USD $1.97
Unit Price: USD $1.9712
≥1 USD $1.9712
≥10 USD $1.59456
≥100 USD $1.289376
≥500 USD $1.208064
≥1000 USD $1.194864
Inventory: 1665
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Length 3.81mm
Height 2.79mm
Technical
Impedance - Unbalanced/Balanced 75 / 75Ohm
Turns Ratio - Primary:Secondary 1:1
Transformer Type RF TRANSFORMER
Insertion Loss (dB) 0.9 dB
Frequency Range 1MHz~500MHz
Physical Dimension L3.81XB3.81XH2.79 (mm)
Depth 3.81mm
Min Operating Temperature -40°C
Max Operating Temperature 85°C
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Published 2010
Packaging Tape & Reel (TR)
Physical
Number of Pins 5
Package / Case 5-SMD Module
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 9 Weeks
Alternative Model
