CX2038LNLT
RoHS
RoHS compliant
RoHS compliantPackage 5-SMD Module
Category RF/IF and RFID / Balun
Description
RF Transformer 1:1 0.5MHz to 1500MHz Surface Mount
PDF
/
Buying Options
Total Price: USD $4.17
Unit Price: USD $4.168458
≥1 USD $4.168458
≥200 USD $1.663444
≥500 USD $1.608303
≥1000 USD $1.580732
Inventory: 7201
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Width 3.81mm
Length 3.81mm
Height 2.79mm
Technical
Impedance - Unbalanced/Balanced 75 / 75Ohm
Cut-off Frequency-Min 4.5MHz
Cut-off Frequency-Max 1500MHz
Return Loss-Min 14dB
Insertion Loss (Max) 2.0dB
Turns Ratio - Primary:Secondary 1:1
Transformer Type RF TRANSFORMER
Frequency Range 4.5MHz~1.5GHz
Operating Temperature (Min) -40°C
Physical Dimension L3.81XB3.81XH2.79 (mm)
Operating Temperature (Max) 85°C
Additional Feature IMPEDANCE RATIO IS 75:75; HEIGHT DIM INCLUDES TERMINALS ALSO
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Published 2010
Packaging Tape & Reel (TR)
Physical
Package / Case 5-SMD Module
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 9 Weeks
