RoHS
/
Package 5-SMD Module
Category RF/IF and RFID / Balun
Description Audio Transformers / Signal Transformers SMD Wideband RF Xfmr
PDF
/
Inventory: 3242
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Mount Surface Mount
Mounting Type Surface Mount
Package / Case 5-SMD Module

Technical

Packaging Tape & Reel (TR)
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination SMD/SMT
ECCN Code EAR99
Max Operating Temperature 25°C
Min Operating Temperature 0°C
Physical Dimension 4.3mm X 2.69mm X 3.81mm
Frequency Range 5MHz~200MHz
Transformer Type RF TRANSFORMER
Insertion Loss (Max) 1.2dB
Turns Ratio (NpNs) 1:2CT
Return Loss-Min 7dB
Cut-off Frequency-Max 200MHz
Cut-off Frequency-Min 65MHz
Impedance - Unbalanced/Balanced 1:4
Phase Difference

Dimensions

Height 5.3mm
Length 4.3mm
Width 3.81mm

Compliance

RoHS Status Non-RoHS Compliant
