EHF-FD1617
RoHS
/
Package /
Category RF/IF and RFID / Balun
Description
BALUN 130MHZ-500MHZ 50/200 OHM
PDF
/
Buying Options
Total Price: USD $11.74
Unit Price: USD $11.73915
≥1 USD $11.73915
≥10 USD $9.63205
≥100 USD $9.3309
≥500 USD $9.0307
≥1000 USD $8.72955
Inventory: 2138
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Dimensions
Width 3.2mm
Height 0.65mm
Technical
Phase Difference 180° ±10°
Impedance - Unbalanced/Balanced 50 / 200Ohm
Cut-off Frequency-Min 380MHz
Cut-off Frequency-Max 430MHz
Turns Ratio (NpNs) 1:2
Insertion Loss (Max) 2.0dB
Transformer Type RF TRANSFORMER
Frequency Range 130MHz~500MHz
Physical Dimension 3.2mm X 1.6mm X 0.65mm
Reach Compliance Code unknown
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Series EHF
Published 2000
Packaging Cut Tape (CT)
Physical
Mounting Type Surface Mount
Mount Surface Mount
