EHF-4BE5250
RoHS
/
Package 0603 (1608 Metric)
Category RF/IF and RFID / Balun
Description
BALUN 5.15-5.35GHZ 50/100 0603
PDF
/
Buying Options
Total Price: USD $10.7
Unit Price: USD $10.69605
≥1 USD $10.69605
≥10 USD $8.7761
≥100 USD $8.5025
≥500 USD $8.22795
≥1000 USD $7.9534
Inventory: 11507
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Dimensions
Width 1.6mm
Height 0.65mm
Technical
Phase Difference 180° ±15°
Impedance - Unbalanced/Balanced 50 / 100Ohm
Cut-off Frequency-Min 5150MHz
Cut-off Frequency-Max 5350MHz
Insertion Loss (Max) 1.2dB
Transformer Type RF TRANSFORMER
Frequency Range 5.15GHz~5.35GHz
Physical Dimension 1.6mm X 0.8mm X 0.65mm
Case Code (Imperial) 0603
Case Code (Metric) 1608
Reach Compliance Code unknown
Resistance 500mOhm
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Series EHF
Published 2004
Packaging Tape & Reel (TR)
Physical
Package / Case 0603 (1608 Metric)
Mounting Type Surface Mount
Mount Surface Mount
