RoHS
/
Package 0805 (2012 Metric)
Category RF/IF and RFID / Balun
Description BALUN 2400-2500 MHZ 50/50 OHM
PDF
/
Inventory: 2264
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Lead Free Lead Free
RoHS Status RoHS Compliant

Dimensions

Width 1.25mm
Length 2mm
Height 0.95mm

Technical

Phase Difference 180° ±15°
Impedance - Unbalanced/Balanced 50 / 100Ohm
Cut-off Frequency-Min 2400MHz
Cut-off Frequency-Max 2500MHz
Insertion Loss (Max) 1.0dB
Transformer Type RF TRANSFORMER
Frequency Range 2.4GHz~2.5GHz
Physical Dimension 2.0mm X 1.25mm X 0.95mm
Case Code (Imperial) 0805
Case Code (Metric) 2012
Reach Compliance Code unknown
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Series EHF
Published 2002
Packaging Tape & Reel (TR)

Physical

Package / Case 0805 (2012 Metric)
Mounting Type Surface Mount
Mount Surface Mount
