LDB212G4020C-001
RoHS
RoHS compliant
RoHS compliantPackage 0805 (2012 Metric)
Category RF/IF and RFID / Balun
Description
BALUN, 2.4GHZ, 50/200OHM, 0603 - More Details
PDF
/
Buying Options
Total Price: USD $0.14
Unit Price: USD $0.1387
≥1 USD $0.1387
≥10 USD $0.114
≥100 USD $0.1102
≥500 USD $0.1064
≥1000 USD $0.10355
≥4000 USD $0.09215
Inventory: 1159
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 1.25mm
Length 2mm
Height 0.95mm
Technical
Impedance - Unbalanced/Balanced 50 / 200Ohm
Transformer Type RF TRANSFORMER
Insertion Loss (dB) 1.1 dB
Frequency Range 2.3GHz~2.5GHz
Application SIGNAL
Impedance 200Ohm
Physical Dimension L2.0XB1.25XH0.95 (mm)
Case Code (Imperial) 0805
Case Code (Metric) 2012
Frequency 2.4GHz
Depth 1.25mm
Subcategory Other Transformers
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Terminal Finish Tin (Sn)
ECCN Code EAR99
Termination SMD/SMT
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series LDB
Packaging Tape & Reel (TR)
Physical
Number of Pins 6
Package / Case 0805 (2012 Metric)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 10 Weeks
