DXP18BN7514TL
RoHS
RoHS compliant
RoHS compliantPackage 0603 (1608 Metric)
Category RF/IF and RFID / Balun
Description
Audio & Signal Transformers 0603 75ohm Balun
PDF
/
Inventory: 1372
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Lifecycle Status NRND (Last Updated: 1 month ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 0603 (1608 Metric)
Number of Pins 6
Technical
Packaging Tape & Reel (TR)
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination SMD/SMT
ECCN Code EAR99
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Depth 800μm
Case Code (Metric) 1608
Case Code (Imperial) 0603
Frequency Range 50MHz~870MHz
Insertion Loss (dB) 1.5 dB
Transformer Type RF TRANSFORMER
Turns Ratio - Primary:Secondary 1:2
Cut-off Frequency-Max 870MHz
Cut-off Frequency-Min 50MHz
Impedance - Unbalanced/Balanced 75 / 300Ohm
Dimensions
Height 0.45mm
Length 1.6mm
Width 800μm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
