MABAES0060
RoHS
RoHS compliant
RoHS compliantPackage 6-SMD (5 Leads), Flat Lead
Category RF/IF and RFID / Balun
Description
BALUN 300KHZ-200MHZ 1:1 6SMD
PDF
/
Buying Options
Total Price: USD $2.68
Unit Price: USD $2.684
≥1 USD $2.684
≥10 USD $2.17184
≥100 USD $1.756128
≥500 USD $1.645424
≥1000 USD $1.571416
≥3000 USD $1.525181
Inventory: 15162
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 14 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 6-SMD (5 Leads), Flat Lead
Number of Pins 5
Technical
Packaging Tape & Reel (TR)
Published 2008
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination SMD/SMT
ECCN Code EAR99
Terminal Finish Gold (Au) - with Nickel (Ni) barrier
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Power Rating 500mW
Depth 3.81mm
Physical Dimension L3.81XB3.81XH3.8 (mm)
Max DC Current 500mA
Lead/Base Style Gull Wing
Frequency Range 300kHz~200MHz
Insertion Loss (dB) 1.5 dB
Transformer Type RF TRANSFORMER
Return Loss-Min 10dB
Cut-off Frequency-Max 200MHz
Cut-off Frequency-Min 0.3MHz
Impedance - Unbalanced/Balanced 1:1
Dimensions
Height 2.67mm
Length 3.81mm
Width 3.81mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
