MABA-010129-CT4A40
RoHS
RoHS compliant
RoHS compliantPackage 6-SMD (5 Leads), Gull Wing
Category RF/IF and RFID / Balun
Description
BALUN 5MHZ-1.2GHZ 50/75 6SMD GW
PDF
/
Buying Options
Total Price: USD $4.03
Unit Price: USD $4.028
≥1 USD $4.028
≥10 USD $3.30505
≥100 USD $3.2015
≥500 USD $3.09795
≥1000 USD $2.99535
Inventory: 1078
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 6-SMD (5 Leads), Gull Wing
Technical
Packaging Tape & Reel (TR)
Published 2009
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination SMD/SMT
ECCN Code EAR99
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Additional Feature HEIGHT DIM. INCLUDES TERMINALS ALSO; CENTER TAPPED SECONDARY; IMPEDANCE RATIO IS 1:4
Power Rating 631mW
Physical Dimension L4.27XB2.69XH3.61 (mm)
Max DC Current 600mA
Frequency Range 5MHz~1.2GHz
Transformer Type RF TRANSFORMER
Insertion Loss (Max) 1.2dB
Return Loss-Min 16dB
Cut-off Frequency-Max 1200MHz
Cut-off Frequency-Min 5MHz
Impedance - Unbalanced/Balanced 50 / 75Ohm
Dimensions
Height 3.61mm
Length 4.27mm
Width 2.69mm
Compliance
RoHS Status ROHS3 Compliant
