MABA-007748-CT1160
RoHS
RoHS compliant
RoHS compliantPackage 6-SMD (5 Leads), Flat Lead
Category RF/IF and RFID / Balun
Description
BALUN 5MHZ-1.2GHZ 1:1 6SMD FLAT
PDF
/
Buying Options
Total Price: USD $2.21
Unit Price: USD $2.21255
≥1 USD $2.21255
≥10 USD $1.81545
≥100 USD $1.75845
≥500 USD $1.70145
≥1000 USD $1.6454
Inventory: 1185
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 3.81mm
Length 3.81mm
Height 3.81mm
Technical
Impedance - Unbalanced/Balanced 1:1
Cut-off Frequency-Min 5MHz
Cut-off Frequency-Max 1200MHz
Turns Ratio (NpNs) 1:1
Insertion Loss (Max) 3.0dB
Transformer Type RF TRANSFORMER
Frequency Range 5MHz~1.2GHz
Operating Temperature (Min) -20°C
Physical Dimension L3.81XB3.81XH3.81 (mm)
Operating Temperature (Max) 85°C
Packing Method TAPE & REEL
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Discontinued
Pbfree Code yes
Published 2010
Packaging Cut Tape (CT)
Physical
Package / Case 6-SMD (5 Leads), Flat Lead
Mounting Type Surface Mount
Mount Surface Mount
