3700BL15B200E
RoHS
RoHS compliant
RoHS compliantPackage 0805 (2012 Metric)
Category RF/IF and RFID / Balun
Description
JOHANSON TECHNOLOGY 3700BL15B200E Baluns Transformer, SMD, 3.4 GHz, 4 GHz, 50ohm, 200ohm, 1.2 dB, 0805
PDF
/
Buying Options
Total Price: USD $0.59
Unit Price: USD $0.5909
≥1 USD $0.5909
≥10 USD $0.48545
≥100 USD $0.47025
≥500 USD $0.45505
≥1000 USD $0.43985
Inventory: 1179
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
REACH SVHC Unknown
Technical
Phase Difference 180° ±20°
Impedance - Unbalanced/Balanced 50 / 200Ohm
Return Loss-Min 9.5dB
Return Loss 9.5 dB
Insertion Loss (Max) 1.2dB
Insertion Loss (dB) 1.2 dB
Frequency Range 3.4GHz~4GHz
Max Frequency 4GHz
Impedance 200Ohm
Case Code (Imperial) 0805
Case Code (Metric) 2012
Frequency 3.7GHz
Composition Ceramic
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Termination SMD/SMT
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series 3700
Published 2005
Packaging Tape & Reel (TR)
Physical
Package / Case 0805 (2012 Metric)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 11 Weeks
