1720BL15B0050E
RoHS
RoHS compliant
RoHS compliantPackage 0805 (2012 Metric)
Category RF/IF and RFID / Balun
Description
BALUN 625MHZ-2.8GHZ 50/50 0805
PDF
/
Buying Options
Total Price: USD $0.37
Unit Price: USD $0.374177
≥1 USD $0.374177
≥10 USD $0.301967
≥30 USD $0.27177
≥100 USD $0.233696
≥500 USD $0.216629
≥1000 USD $0.206125
Inventory: 1174
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 0805 (2012 Metric)
Technical
Packaging Tape & Reel (TR)
Published 2016
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Packing Method TR
Reach Compliance Code unknown
Case Code (Metric) 2012
Case Code (Imperial) 0805
Physical Dimension L2.01XB1.24XH0.94 (mm)
Bandwidth 2.19 GHz
Frequency Range 625MHz~2.8GHz
Transformer Type RF TRANSFORMER
Insertion Loss (Max) 1.5dB
Return Loss-Min 9.5dB
Cut-off Frequency-Max 2815MHz
Cut-off Frequency-Min 625MHz
Impedance - Unbalanced/Balanced 50 / 50Ohm
Phase Difference 180° ±10°
Dimensions
Height 1.05mm
Length 2.01mm
Compliance
RoHS Status RoHS Compliant
