3-1-1WL
RoHS
RoHS compliant
RoHS compliantPackage 6-SMD, Gull Wing
Category RF/IF and RFID / Balun
Description
RF Transformer 1:1 6Term. Gull Wing SMD
PDF
/
Inventory: 9195
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Length 7.62mm
Technical
Insertion Loss (Max) 3.0dB
Turns Ratio - Primary:Secondary 1:1
Transformer Type RF TRANSFORMER
Insertion Loss (dB) 3 dB
Frequency Range 150kHz~400MHz
Lead/Base Style Gull Wing
Frequency 400MHz
Depth 10.92mm
Min Operating Temperature 0°C
Max Operating Temperature 70°C
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e1
Published 2012
Packaging Tube
Physical
Number of Pins 6
Package / Case 6-SMD, Gull Wing
Mounting Type Surface Mount
Mount Surface Mount
