2-2-1DL
RoHS
RoHS compliant
RoHS compliantPackage 6-DIP (0.300, 7.62mm)
Category RF/IF and RFID / Balun
Description
RF Transformer 1:1.41 6Term. PC Pin Thru-Hole
PDF
/
Inventory: 8214
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Length 7.62mm
Technical
Insertion Loss (Max) 3.0dB
Turns Ratio - Primary:Secondary 1:1.41
Transformer Type RF TRANSFORMER
Insertion Loss (dB) 3 dB
Frequency Range 70kHz~200MHz
Lead/Base Style PC Pin
Frequency 200MHz
Depth 8.83mm
Additional Feature IMPEDANCE RATIO IS 2:1
Min Operating Temperature 0°C
Max Operating Temperature 70°C
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e1
Published 2012
Packaging Tube
Physical
Number of Pins 6
Package / Case 6-DIP (0.300, 7.62mm)
Mounting Type Through Hole
Mount Through Hole
